Pontiac G6 I (2004-2009) (left front of engine compt, on left rear side of Wiring diagram
This page shows the only wiring diagram for the component.(left front of engine compt, on left rear side of, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (left front of engine compt, on left rear side of (1 of 1)
2 29 19 592 1969 317 DRL RLY CTRL HIGH BEAM IN FOG LMP RLY CTRL
AMBIENT LIGHT SENSOR (TOP CENTER OF DASH, UNDER DEFROST DEFLECTOR)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CORE SUPPORT, BETWEEN
DK GRN WIRE
DRL FUSE 46
DRL RELAY 48
FOG LAMP SWITCH
FRT FOG LP FUSE 10
FRT FOG RELAY 36
FTP
GRN WIRE
HEAD
HIGH BEAM IND
HIGH BEAM RELAY 35
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LH HI BEAM FUSE 11
LH LOW FUSE 7
LOGIC
LOW BEAM RELAY 38
LT GRN WIRE
LT GRN/BLK WIRE
OFF AUTO PARK
ON IND.
ORG/ WIRE
PNK PNK WIRE
PNK PPL WIRE
PNK/WHT WIRE
PPL
PPL PPL
PPL/WHT WIRE
RH HI BEAM FUSE 12
RH LOW BEAM FUSE 9
RIGHT FRONT FOG LAMP LEFT FRONT FOG LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SER DATA
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
