Pontiac G6 I (2004-2009) high sensitivity setting Wiring diagrams
This page contains all the electrical diagrams for the component. high sensitivity setting, in which he is found in the car Pontiac G6 I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high sensitivity setting (1 of 2)
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
B/U LP RELAY
BACKUP LAMP SUPPLY VOLTAGE
BCK/UP LAMPS FUSE 17
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DRIVER WINDOW SWITCH VOLT
EMERGENCY
EMERGENCY IND
GREEN LED SIG
GROUND
GRY WIRE
HEADLIGHT SENSOR (MIRROR SIDE)
HIGH SENSITIVITY SETTING
HOT AT ALL TIMES
HOT IN ON OR ACC
INSIDE REARVIEW MIRROR
KEYPAD GREEN LED IND
KEYPAD RED WIRE
KEYPAD SIG
LED IND
LOGIC
LOW SENSITIVITY SETTING
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAX
OFF MIN
ONSTAR
ONSTAR IND
ONSTAR KEYPAD
PASSENGER WINDOW SWITCH (IF EQUIPPED) VOLT
PHONE
PHONE IND
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
RED LED SIG WIRE
REVERSE LAMP RELAY CONTROL
ROOF/HEAT SEAT FUSE
SPLY VOLT
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (UNDER RIGHT SIDE OF DASH)
W/ ONSTAR
W/O ONSTAR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit, convertible -> HIGH SENSITIVITY SETTING
Wiring diagram high sensitivity setting (2 of 2)
11 6 3 2 KEYPAD SIG SPLY VOLT GREEN LED SIG
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
B/U LP RELAY 33
BACKUP LAMP SUPPLY VOLTAGE
BCK/UP LAMPS FUSE 17
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
EMERGENCY
EMERGENCY IND
GROUND
GRY WIRE
HEADLIGHT SENSOR (MIRROR SIDE)
HIGH SENSITIVITY SETTING
HOT AT ALL TIMES
HOT IN ON OR ACC
INSIDE REARVIEW MIRROR
KEYPAD GREEN LED IND
KEYPAD RED WIRE
LED IND
LOGIC
LOW SENSITIVITY SETTING
LT BLU WIRE
LT GRN/BLK WIRE
MAX
OFF MIN
ONSTAR
ONSTAR IND
ONSTAR KEYPAD
PHONE
PHONE IND
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
RED LED SIG WIRE
REVERSE LAMP RELAY CONTROL
ROOF/HEAT SEAT FUSE
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (UNDER RIGHT SIDE OF DASH)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit, except convertible -> HIGH SENSITIVITY SETTING
