Pontiac G6 I (2004-2009) drv seat fuse 2 Wiring diagrams
This page contains all the electrical diagrams for the component. drv seat fuse 2, in which he is found in the car Pontiac G6 I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram drv seat fuse 2 (1 of 2)
Go to component -> 2-way adjustable power seat circuit -> DRV SEAT FUSE 2
Wiring diagram drv seat fuse 2 (2 of 2)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER SWITCH (6-WAY)
DRV SEAT FUSE 2
FRONT DOWN
FRONT UP RWD
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
REAR DOWN
REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL)
REAR UP
RED/BLK WIRE
SEAT FRONT VERTICAL MOTOR (IN LEFT FRONT OF PASSENGER COMPT, UNDER DRIVER SEAT)
SEAT HORIZONTAL MOTOR (IN LEFT FRONT OF PASSENGER COMPT, UNDER DRIVER SEAT)
SEAT REAR VERTICAL MOTOR (IN LEFT FRONT OF PASSENGER COMPT, UNDER DRIVER SEAT)
TAN WIRE
YEL WIRE
Go to component -> 6-way power seat circuit -> DRV SEAT FUSE 2
