Pontiac G6 I (2004-2009) driver seat adjuster switch folding top control module Wiring diagram
This page shows the only wiring diagram for the component.driver seat adjuster switch folding top control module, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat adjuster switch folding top control module (1 of 1)
ADJUSTABLE PEDAL POSITION SWITCH ADJUSTABLE PEDAL MODULE
ADJUSTER FRONT SEAT MANUAL ADJUSTER FRONT SEAT POWER 3 4
AUTOMATIC A/C MANUAL A/C
BATT POS VOL LOGIC
BLK WIRE
BLOWER MOTOR CONTROL MODULE (AUTOMATIC A/C)
BODY CONTROL MODULE (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH)
BRN WIRE
C/FAN 2 FUSE 18
COOLING FAN 2 RELAY 30
DRIVER SEAT ADJUSTER SWITCH FOLDING TOP CONTROL MODULE
DRV ST FUSE 2
EMISSION 2 FUSE 5
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE
FOLDING TOP FUSE 3
FROM DOOR LOCKS FUSE (DIAGRAM 2 OF 5)
FROM HORN FUSE 8 (DIAGRAM 3 OF 5)
FRT FOG LP FUSE 10
FRT FOG RELAY 36
FUEL FUSE 25 PARK LPS FUSE 6
FUEL/ PMP RELAY 37
HVAC BLOWER HIGH RELAY
HVAC CONTROL MODULE
HVAC CTRL (IGN) FUSE HVAC BLOWER FUSE
INTERIOR LIGHTS FUSE
LOGIC
ONSTAR FUSE
OUTSIDE REARVIEW MIRROR SWITCH
PARK LPS RELAY 27
PEDAL FUSE
POWER MIRRORS FUSE
RBEC 2 FUSE 23
REAR FUSE BLOCK
RED WIRE
RELAY
RLY CTRL
RR QUARTER WDO FUSE 1
RUN RLY FUSE 19
RUN WIRE
SLDG PNL ROOF FUSE 9
STOP LP FUSE 47
STOP LP RELAY 49
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
TO RUN CRANK RELAY 32 (DIAGRAM 5 OF 5)
TRUNK FUSE 22
TRUNK RELAY 36
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE
WHT WIRE
WINDOW MOTOR- LR/RR
WIPER 1 RELAY 39
WIPER FUSE 14
Go to component -> Power distribution circuit (4 of 5) -> DRIVER SEAT ADJUSTER SWITCH FOLDING TOP CONTROL MODULE
