Pontiac G6 I (2004-2009) decklid latch extend signal unlatched signal 12 volt reference Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP FUSE 12 DECKLID HINGE DOWEL PIN SIGNAL HEADLINER DOWEL SIGNAL DECKLID LATCH EXTEND SIGNAL UNLATCHED SIGNAL 12 VOLT REFERENCE DK BLU WIRE DK GRN WIRE FOLDING TOP CONTROL MODULE (RIGHT SIDE OF REAR COMPARTMENT) FOLDING TOP FUSE 3 FOLDING TOP HEADER LATCH FOLDING TOP HEADER LATCH CYLINDER (IN PASSENGER COMPARTMENT) FOLDING TOP PUMP MOTOR (RIGHT SIDE OF REAR COMPARTMENT) GRN WIRE GRY WIRE HOT AT ALL TIMES LUGGAGE BARRIER LIMIT SWITCH SIGNAL HEADLINER LATCH SIGNAL ORG/ WIRE POWER WINDOWS SYSTEM PPL PPL/WHT WIRE REAR COMPARTMENT CYLINDER EXTENDED REAR COMPARTMENT LID RELEASE SWITCH (IN REAR COMPARTMENT LID) REAR FUSE BLOCK (LEFT SIDE OF REAR COMPARTMENT, BEHIND LEFT REAR WHEEL WELL) RED WIRE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE REQUEST SIGNAL RETRACTABLE ROOF CLOSE SIGNAL ROOF CLOSED SIGNAL ROOF LOCKED SIGNAL ROOF LOCKED SIGNAL HEADER LATCHED ROOF OPEN SIGNAL ROOF OPEN SIGNAL SERIAL DATA (-) SERIAL DATA (+) VALVE 1 CONTROL VALVE 2 CONTROL WHT WIRE
