Pontiac G6 I (2004-2009) 28 27 53 33 gmlan data bus + gmlan data bus - Wiring diagram
This page shows the only wiring diagram for the component.28 27 53 33 gmlan data bus + gmlan data bus -, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 28 27 53 33 gmlan data bus + gmlan data bus - (1 of 1)
1 7 LS GMLAN DATA LS GMLAN DATA
1 9 5060 5060 LS GMLAN DATA LS GMLAN DATA
2 1 5060 5060 LS GMLAN DATA LS GMLAN DATA
2 3 LS GMLAN DATA LS GMLAN DATA
28 27 53 33 GMLAN DATA BUS + GMLAN DATA BUS -
3.5L EXCEPT 3.5L
32 2 5060 5060 LS GMLAN DATA LS GMLAN DATA
5 6 5060 5060 LS GMLAN DATA LS GMLAN DATA
5 6 LS GMLAN DATA LS GMLAN DATA
A/T
A/T M/T
BLK WIRE
BLK/WHT WIRE
DATA LINK CONNECTOR (DLC) (ON LOWER LEFT OF DASH)
DIGITAL RADIO RECEIVER
DK GRN WIRE
ENGINE CONTROL MODULE (ECM)
FOLDING TOP CONTROL MODULE
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
HS GMLAN DATA BUS - HS GMLAN DATA BUS + HS GMLAN DATA BUS + HS GMLAN DATA BUS -
HVAC CONTROL MODULE (IN LOWER CENTER OF DASH, BELOW RADIO)
HVAC CTRL (BATT) FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW SPEED GMLAN SERIAL DATA LOW SPEED GMLAN SERIAL DATA
LS GMLAN DATA LS GMLAN DATA
M/T
POWER DISTRIBUTION SYSTEM
RADIO
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
TAN WIRE
TAN/ BLK WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT REAR OF ENGINE COMPT, NEAR STRUT TOWER)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (UNDER RIGHT SIDE OF DASH)
W/ ABS
W/ CONVERTIBLE
W/ DIGITAL AUDIO
W/ DIGITAL RADIO
W/ NAVIGATION
W/ POWER STEERING
W/O ABS
W/O DIGITAL AUDIO
W/O DIGITAL RADIO
W/O DIGITAL RADIO W/ DIGITAL RADIO
W/O NAVIGATION
W/O POWER STEERING
Go to component -> Computer data lines circuit -> 28 27 53 33 GMLAN DATA BUS + GMLAN DATA BUS -
