Pontiac G6 I (2004-2009) 11 6 3 2 keypad sig sply volt green led sig Wiring diagram

11 6 3 2 KEYPAD SIG SPLY VOLT GREEN LED SIG AMBIENT LIGHT SENSOR (WINDSHIELD SIDE) B/U LP RELAY 33 BACKUP LAMP SUPPLY VOLTAGE BCK/UP LAMPS FUSE 17 BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF CENTER CONSOLE, NEAR DASH) BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN/WHT WIRE EMERGENCY EMERGENCY IND GROUND GRY WIRE HEADLIGHT SENSOR (MIRROR SIDE) HIGH SENSITIVITY SETTING HOT AT ALL TIMES HOT IN ON OR ACC INSIDE REARVIEW MIRROR KEYPAD GREEN LED IND KEYPAD RED WIRE LED IND LOGIC LOW SENSITIVITY SETTING LT BLU WIRE LT GRN/BLK WIRE MAX OFF MIN ONSTAR ONSTAR IND ONSTAR KEYPAD PHONE PHONE IND REAR FUSE BLOCK (LEFT SIDE OF REAR COMPT, BEHIND LEFT REAR WHEEL WELL) RED LED SIG WIRE REVERSE LAMP RELAY CONTROL ROOF/HEAT SEAT FUSE VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (UNDER RIGHT SIDE OF DASH) WHT WIRE YEL WIRE YEL/BLK WIRE
