Pontiac G6 I (2004-2009) 1 2 3 4 ground heated seat sw sig accy voltage battery Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 ground heated seat sw sig accy voltage battery, which is found in the car Pontiac G6 I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 ground heated seat sw sig accy voltage battery (1 of 1)
1 2 3 4 GROUND HEATED SEAT SW SIG ACCY VOLTAGE BATTERY
1 2 SEAT BACK ELEMENT CTRL SEAT BACK ELEMENT VOLTAGE
ACCY VLT
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT
DRIVER HEATED SEAT BACK ELEMENT (UNDER UPHOLSTERY OF DRIVER SEAT BACK)
DRIVER HEATED SEAT CUSHION ELEMENT (UNDER UPHOLSTERY OF DRIVER SEAT BOTTOM)
DRIVER HEATED SEAT CUSHION TEMPERATURE SENSOR
DRIVER HEATED SEAT SWITCH
GRY WIRE
HEATED SEAT SW SIG
HOT AT ALL TIMES
HOT IN RUN OR ACC
LOGIC
LOGIC INSTRUMENT PANEL LAMP SPLY VOLT
LOW HEATED SEAT SW SIG
LT BLU/BLK WIRE
OFF
PASSENGER HEATED SEAT BACK ELEMENT (UNDER UPHOLSTERY OF PASSENGER SEAT BACK)
PASSENGER HEATED SEAT CUSHION TEMPERATURE SENSOR
PASSENGER HEATED SEAT SWITCH
RED WIRE
RED/WHT WIRE
ROOF/ HEAT SEAT FUSE
SIDE OF CENTER CONSOLE, NEAR DASH)
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> 1 2 3 4 GROUND HEATED SEAT SW SIG ACCY VOLTAGE BATTERY
