Shift interlock circuit for Pontiac Firebird IV (1993-2002)
Shift interlock circuit
A/T SHIFT LOCK CONTROL ACTUATOR SOLENOID (IN CONSOLE,
BLK/WHT WIRE
BRAKE TRANSMISSION SHIFT INTERLOCK SWITCH
DK GRN/WHT WIRE
FORWARD OF SHIFT CONTROL LEVER)
HATCH RELEASE RELAY
HOT IN RUN, BULB TEST OR START GAUGES FUSE 9
I/P FUSE BLOCK
ISOLATION DIODE (BTSI) (1 AMP)
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWER TOPS
POWERTRAIN CONTROL MODULE (PCM)
STOPLAMP/TCC SWITCH ASSEMBLY
TAN/WHT WIRE
