Pontiac Firebird IV (1993-2002) Instrument illumination circuit

A/T ASHTRAY LAMP BLK WIRE BRN WIRE COURTESY LAMPS CIRCUIT DK GRN WIRE ELECTRONIC TRACTION CONTROL SWITCH OR SECOND GEAR START SWITCH FOG LAMP SWITCH FOLDING TOP SWITCH GAUGES FUSE 9 GRY WIRE GRY/BLK WIRE HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START HOT WITH LAMPS ON HVAC CONTROL I/P DIMMER FUSE 16 I/P DIMMER SWITCH I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT CLUSTER LEFT DOOR ILLUMINATION LAMP M/T MAX MIN NCA WIRE OFF HEAD PARK ORG/ WIRE PARK LIGHTS RELAY PNK WIRE PRNDL ILLUMINATION LAMP RADIO RADIO (1999) STEERING WHEEL CONTROLS RIGHT DOOR ILLUMINATION LAMP SOLID STATE STG WHL CNTRL FUSE 13 TAIL LTS FUSE 5 WHT WIRE
