Pontiac Firebird IV (1993-2002) wiper/wash fuse 14 Wiring diagram
This page shows the only wiring diagram for the component.wiper/wash fuse 14, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper/wash fuse 14 (1 of 1)
BANK 1 SENSOR 1
BANK 1 SENSOR 2 (1999 VIN G, 2000-01 ALL)
BANK 1 SENSOR 3 (1999 VIN K) BANK 2 SENSOR 1
BANK 2 SENSOR 2 (VIN G)
BODY CONTROL MODULE (BCM)
BOTTOM UNDERHOOD FUSE BLOCK
BOTTOM UNDERHOOD FUSE BLOCK INJ 1 FUSE
BRN WIRE
DK BLU WIRE
DRIVER WINDOW SWITCH
ENG SEN FUSE
FOLDING TOP RELAY
FOLDING TOP SWITCH
FROM IGNITION SWITCH PIN E (DIAGRAM 2 OF 4)
FROM INJ 2 FUSE (DIAGRAM 4 OF 4)
FRONT PASSENGER WINDOW SWITCH
FUEL INJECTOR 1 FUEL INJECTOR 3
FUEL INJECTOR 2
FUEL INJECTOR 2 (VIN K)
FUEL INJECTOR 4
FUEL INJECTOR 5
FUEL INJECTOR 7 (VIN G) FUEL INJECTOR 6 (VIN K) FUEL INJECTOR 4 (VIN K)
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
I/P FUSE BLOCK
IGNITION COIL/ MODULE 3 (2000- 01) IGNITION COIL/ MODULE 5 (2000- 01)
IGNITION COIL/ MODULE 8 (2000- 01) IGNITION COIL/ MODULE 6 (2000- 01)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
NCA WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/WHT WIRE
RADIO
RADIO FUSE 17
REVERSE INHIBIT SOLENOID (M/T) SKIP SHIFT SOLENOID (M/T)
STEERING WHEEL CONTROLS
STG WHL CNTRL FUSE 3
STOPLAMP SWITCH (A/T) MASS AIRFLOW (MAF) SENSOR HEATED OXYGEN SENSOR
TO INJ 1 FUSE (DIAGRAM 4 OF 4) INJ 2 FUSE
VIN G ONLY
WINDOW CONTROL MODULE
WINDOWS CIRCUIT BREAKER
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WIPER/WASH FUSE 14
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> WIPER/WASH FUSE 14
