Pontiac Firebird IV (1993-2002) right power door lock switch Wiring diagram
This page shows the only wiring diagram for the component.right power door lock switch, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power door lock switch (1 of 1)
AMPLIFIER
ASHTRAY LAMP
ASHTRAY LAMP (CONVERTIBLE)
AUXILIARY POWER OUTLET (TAPED TO I/P HARNESS)
BLK WIRE
BLOWER MOTOR RELAY
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CAMARO
CIGAR LIGHTER
COOLANT FAN 3 RELAY
COURTESY/ READING LAMPS
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS (DRL) MODULE
ELECTRONIC BRAKE CONTROL MODULE
FIREBIRD HEADLAMP OPENING ACTUATOR CONTROL MODULE
FOG LAMP SWITCH
GULF STATES
HEADLAMP SWITCH
HVAC CONTROL
HVAC CONTROL I/P DIMMER SWITCH
HVAC ILLUMINATION LAMPS
I/P COMPARTMENT LAMP
IGNITION KEY WARNING SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSIDE REARVIEW MIRROR
INSTRUMENT CLUSTER
INSTRUMENT PANEL CLUSTER (2001)
LEFT DOOR ILLUMINATION LAMP
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT HEADLAMP
LEFT HEADLAMP OPENING DOOR ASSEMBLY (PONTIAC)
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT POWER DOOR LOCK SWITCH OUTSIDE REAR VIEW MIRROR SWITCH
LEFT POWER WINDOW SWITCH
M/T A/T
MODULE BREAKOUT)
NCA WIRE
RADIO
RADIO POWER ANTENNA
REAR COMPARTMENT LID RELEASE SWITCH
REAR DEFOGGER SWITCH
RIGHT DOOR ILLUMINATION LAMP
RIGHT FRONT ENGINE COOLANT FANS
RIGHT FRONT SIDE DOOR LOCK LEFT FRONT SIDE DOOR LOCK
RIGHT POWER DOOR LOCK SWITCH
SEAT BELT SWITCH
SECONDARY AIR INJECT- ION PUMP (5.7L)
SECURITY INDICATOR LED
STEERING WHEEL CONTROLS
THEFT DETERRENT SHOCK SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 3) -> RIGHT POWER DOOR LOCK SWITCH
