Pontiac Firebird IV (1993-2002) rear compartment lid release actuator folding top switch Wiring diagram
This page shows the only wiring diagram for the component.rear compartment lid release actuator folding top switch, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear compartment lid release actuator folding top switch (1 of 1)
BLK WIRE
BLOWER MOTOR
CAMARO
CENTER HIGH MOUNTED STOP LAMP
CENTER HIGH MOUNTED STOP LAMP REAR DEFOGGER GRID
COUPE
FIREBIRD
FOLDING TOP RELAY
FOLDING TOP SWITCH
FOLDING TOP TOP SWITCH (PONTIAC)
FUEL TANK UNIT
LEFT BACK-UP LAMP LEFT TAIL/STOP/ TURN LAMP
LEFT BACK-UP LAMP RIGHT BACK-UP LAMP
LEFT INBOARD TAIL/STOP/ TURN LAMP
LEFT OUTBOARD TAIL/STOP/ TURN LAMP
LEFT SIDE MARKER LAMP
LEFT SIDE MARKER LAMP LICENSE LAMP
LEFT TAIL LAMP
LEFT TAIL/STOP LAMP LEFT TAIL LAMP
NCA WIRE
POWER SEAT CUSHION AIR CONTROL MODULE
POWER SEAT SWITCH
REAR COMPARTMENT LID AJAR INDICATOR SWITCH
REAR COMPARTMENT LID AJAR INDICATOR SWITCH REAR COMPARTMENT LID RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE ACTUATOR FOLDING TOP SWITCH
REAR DEFOGGER GRID
RIGHT BACK-UP LAMP
RIGHT SIDE MARKER LAMP
RIGHT SIDE MARKER LAMP RIGHT INBOARD TAIL/STOP/ TURN LAMP LICENSE LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP RIGHT OUTBOARD TAIL/STOP/ TURN LAMP
RIGHT TAIL/STOP LAMP
RIGHT TAIL/STOP TURN LAMP
W/ ETA
W/O ETA
Go to component -> Ground distribution circuit (3 of 3) -> REAR COMPARTMENT LID RELEASE ACTUATOR FOLDING TOP SWITCH
