Pontiac Firebird IV (1993-2002) lid rly ctrl lid release sig Wiring diagram
This page shows the only wiring diagram for the component.lid rly ctrl lid release sig, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lid rly ctrl lid release sig (1 of 1)
A/T
BATTERY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
COURTESY FUSE 8
ENGINE CONTROLS SYSTEM
HOT AT ALL TIMES
I/P FUSE BLOCK
INSTRU- MENT CLUSTER SYSTEM
ISOLATION DIODE
LID RLY CTRL LID RELEASE SIG
LT BLU WIRE
M/T
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK BRAKE SWITCH
PARK/NEUTRAL POSITION SWITCH (UNDER CONSOLE, NEAR SHIFT CONTROL LEVER)
PWR ACCY FUSE 7
REAR COMPARTMENT LID RELEASE ACTUATOR (IN CARGO COMPT)
REAR COMPARTMENT LID RELEASE RELAY (BEHIND LEFT SIDE OF DASH)
REAR COMPARTMENT LID RELEASE SWITCH
SHIFT INTERLOCK SYSTEM
TAN WIRE
TAN/WHT WIRE
WHT WIRE
Go to component -> Trunk, tailgate, fuel door circuits -> LID RLY CTRL LID RELEASE SIG
