Pontiac Firebird IV (1993-2002) left tail lamp left outboard tail/ stop/ turn lamp Wiring diagram
This page shows the only wiring diagram for the component.left tail lamp left outboard tail/ stop/ turn lamp, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left tail lamp left outboard tail/ stop/ turn lamp (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
CENTER HIGH MOUNTED STOP LIGHT
CRUISE CONTROL SYSTEM
DAYTIME RUNNING LAMPS (DRL) MODULE (BEHIND RADIO, LEFT SIDE OF GLOVE BOX)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK RIGHT TURN INDIC
FLASHER (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE 1
FUSE 2
HAZARD
HAZARD LAMP
HEAD
HEADLAMP SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT TAIL LAMP LEFT INBOARD TAIL/ STOP/ TURN LAMP
LEFT TAIL LAMP LEFT OUTBOARD TAIL/ STOP/ TURN LAMP
LEFT TURN INDIC
LICENSE LAMP
LT BLU WIRE
LT BLU/WHT WIRE
NORMAL
OFF
OPTIONAL
ORG/ WIRE
ORN/
PARK
PPL
PWR ACCY FUSE 7
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT TAIL LAMP RIGHT INBOARD TAIL/ STOP/ TURN LAMP
RIGHT TAIL LAMP RIGHT OUT- BOARD TAIL/ STOP/ TURN LAMP
SOLID STATE
SOUND SYSTEMS
STOP/ HAZARD
STOPLAMP/ TCC SWITCH (ON BRAKE PEDAL BRACKET)
TAIL LTS FUSE 5
TURN B/U
TURN LEFT
TURN RIGHT
TURN SIGNAL LAMP FLASHER
TURN/ HAZARD SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
