Pontiac Firebird IV (1993-2002) left rear courtesy lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear courtesy lamp, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear courtesy lamp (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH)
COURTESY/ READING LAMPS
DK BLU/WHT WIRE
GROUND POWER (BATTERY) COURTESY LAMPS POWER FEED
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) COURTESY FUSE 8
I/P COMPARTMENT LAMP
I/P DIMMER SWITCH
INSIDE REARVIEW MIRROR
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SIDE DOOR LOCK
LEFT REAR COURTESY LAMP
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LAMP
REAR COMPARTMENT LID AJAR INDICATION SWITCH
RIGHT FRONT SIDE DOOR LOCK
RIGHT REAR COURTESY LAMP
WHT WIRE
