Pontiac Firebird IV (1993-2002) front passenger door lock switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger door lock switch, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger door lock switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
COURTESY FUSE 8
DK BLU/WHT WIRE
DRIVER DOOR LOCK
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR LOCK SWITCH
DRIVER DR UNLOCK ALL DOORS LOCK UNLOCK INPUT LOCK INPUT PASS DR UNLOCK
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER DOOR LOCK ACTUATOR
FRONT PASSENGER DOOR LOCK SWITCH
GROUND BAT INTERIOR LTS FEED
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT POWER MIRROR CONTROL SWITCH HARNESS BREAKOUT)
LOCK
ORG/ WIRE
ORG/BLK WIRE
RED WIRE
RED/BLK WIRE
TAN WIRE
TRUNK/TAILGATE/ FUEL DOORS SYSTEM
UNLOCK
WHT WIRE
WINDOW CONTROL MODULE BREAKOUT)
Go to component -> Power door lock circuit -> FRONT PASSENGER DOOR LOCK SWITCH
