Pontiac Firebird IV (1993-2002) driver high driver low pass low Wiring diagram
This page shows the only wiring diagram for the component.driver high driver low pass low, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver high driver low pass low (1 of 1)
AIR BAG FUSE 10
AIR BAG INDICATOR
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER DASH TO RIGHT OF STEERING COLUMN)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER HIGH DRIVER LOW PASS LOW
GAUGES FUSE 9
GROUND CASE GROUND
GRY WIRE
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
IGNITION
INFLATABLE RESTRAINT INSTRUMENT PANEL MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW REAR OF CONSOLE)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT CLUSTER
NCA WIRE
PASS HIGH SERIAL DATA
PNK (I/P HARNESS, AT REAR COMPARTMENT LID RELEASE RELAY BREAKOUT) WIRE
PNK WIRE
PPL
SEAT BELT SIG
SEAT BELT SWITCH
SHORTING BAR
SOLID STATE
SPLICE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit -> DRIVER HIGH DRIVER LOW PASS LOW
