Pontiac Firebird IV (1993-2002) crank signal Wiring diagram
This page shows the only wiring diagram for the component.crank signal, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crank signal (1 of 1)
3.8L
A/T
BATTERY
BATTERY JUNCTION BLOCK
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BULB TEST
CLUTCH PEDAL POSITION SWITCH (ON CLUTCH PEDAL BRACKET)
CRANK SIGNAL
DK GRN WIRE
GENERATOR
IGN MAXI FUSE
IGNITION SWITCH
INSTRUMENT CLUSTER
LOCK
M/T
OFF
PARK/NEUTRAL POSITION SWITCH (UNDER CONSOLE, NEAR SHIFT CONTROL LEVER)
PPL
PPL/WHT WIRE
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY
STARTER RELAY CONTROL
STARTER SOLENOID
STRTR MINIFUSE
UNDERHOOD FUSE BLOCK (IN LEFT FRONT CORNER OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Starting circuit -> CRANK SIGNAL
