Pontiac Firebird IV (1993-2002) cigar/accy fuse 11 Wiring diagram
This page shows the only wiring diagram for the component.cigar/accy fuse 11, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cigar/accy fuse 11 (1 of 1)
2000-01 5.7L ONLY
3 2 PPL
ALL EXCEPT 2000-01 5.7L
BLK WIRE
BLK/WHT WIRE
CIGAR/ACCY FUSE 11
DATA LINK CONNECTOR (DLC) (UNDER DASH, TO RIGHT OF STEERING COLUMN)
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (BELOW REAR OF CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN ENGINE COMPT, BEHIND RIGHT STRUT TOWER)
PPL
SERIAL DATA
STAR CONNECTOR (1999) (2000-01) (UNDER LEFT SIDE OF DASH, NEAR DLC)
Go to component -> Computer data lines -> CIGAR/ACCY FUSE 11
