Pontiac Firebird IV (1993-2002) accelerator, servo control module Wiring diagram
This page shows the only wiring diagram for the component.accelerator, servo control module, which is found in the car Pontiac Firebird IV (1993-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram accelerator, servo control module (1 of 1)
ABS BAT 1 FUSE
ABS BAT 2 FUSE
ACCELERATOR, SERVO CONTROL MODULE
AIR PUMP FUSE
AIR PUMP RELAY (VIN G)
AIR SOLENOID RELAY (1999 W/VIN G)
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BODY CONTROL MODULE (BCM)
BOTTOM UNDERHOOD FUSE BLOCK
COOL FAN FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 RELAY
COOLING FAN 3 RELAY
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENG CTRL FUSE
FUEL PUMP FUSE
FUEL PUMP RELAY
FUSIBLE LINK E
FUSIBLE LINK F
FUSIBLE LINK Z
GENERATOR
GRY WIRE
HEADLAMP OPENING DOOR ACTUATOR CONTROL MODULE
HEADLAMP SWITCH
HL DOOR-HORN FUSE
HORN FUSE
HORN RELAY
I/P 1 FUSE
I/P 2 FUSE
IGN FUSE
L HDLP DOOR FUSE
NCA WIRE
ORG/ WIRE
PCM BAT FUSE
POWERTRAIN CONTROL MODULE (PCM)
R HDLP DOOR FUSE
RED (OR BLK) WIRE
RED WIRE
STARTER SOLENOID
TCS BAT FUSE ABS BAT FUSE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TO CIGAR ACCY FUSE (DIAGRAM 3 OF 4)
TO IGNITION SWITCH PIN B (DIAGRAM 2 OF 4)
TO RADIO ACCY FUSE (DIAGRAM 3 OF 4)
TO TAIL LTS FUSE (DIAGRAM 3 OF 4)
TOP UNDERHOOD FUSE BLOCK
VIN G
VIN K
VIN K VIN G
Go to component -> Power distribution circuit (1 of 4) -> ACCELERATOR, SERVO CONTROL MODULE
