Ground distribution circuit for Pontiac Bonneville X (2000-2005)

Ground distribution circuit (1 of 5)

Get access

A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH DIODE ACCY RELAY AUTOMATIC TRANSAXLE BANK 1 SENSOR 1 BANK 1 SENSOR 2 BLK WIRE BRAKE FLUID LEVEL SWITCH COIL COOL FAN S/P RELAY (SERIES/ PARALLEL) CRUISE CONTROL MODULE DRL RELAY ELECTRONIC BRAKE CONTROL MODULE (EBCM) ENGINE OIL LEVEL SWITCH HEATED OXYGEN SENSOR HORN ASSEMBLY IGN 1 RELAY IGNITION CONTROL MODULE (ICM) INTERNAL MODE SWITCH LEFT COOLING FAN LEFT FRONT PARK/TURN SIGNAL LAMP LEFT LOW BEAM HEADLAMP MASS AIR FLOW (MAF SENSOR) NCA WIRE POWERTRAIN CONTROL MODULE (PCM) RIGHT FRONT PARK/TURN SIGNAL LAMP SPLICE PACK UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) WHT WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH WINDSHIELD WASHER FLUID PUMP WINDSHIELD WIPER MOTOR

Get access

A/T SHIFT LOCK CONTROL SOLENOID AUTO A/C MANUAL A/C BLK WIRE DASH INTEGRATION MODULE (DIM) DRIVER HEATED SEAT MODULE DRIVER SEAT ADJUSTER SWITCH DRIVER'S DOOR MODULE (DDM) FRONT PASSENGER HEATED SEAT MODULE FRONT PASSENGER SEAT ADJUSTER SWITCH FRONT PASSENGER SEAT LUMBAR SWITCH HVAC CONTROL MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER (IPC) LEFT STEERING WHEEL CONTROLS MEMORY SEAT MODULE (MSM) NCA WIRE RIGHT REAR DOOR MODULE (RRDM) RIGHT STEERING WHEEL CONTROLS SPLICE PACK STOPLAMP SWITCH TURN SIGNAL/ MULTIFUNCTION SWITCH W/ HEATED POWER SEATS W/ HEATED SEATS W/ MEMORY POWER SEATS W/ POWER SEATS W/ RECLINER POWER SEATS W/O HEATED POWER SEATS W/O HEATED SEATS W/O MEMORY POWER SEATS W/O POWER SEATS W/O RECLINER POWER SEAT WHT WIRE

Get access

A/T SHIFT LOCK CONTROL SOLENOID AUDIO AMPLIFIER BLK WIRE BLOWER MOTOR CONTROL PROCESSOR CIGAR LIGHTER DATA LINK CONNECTOR (DLC) DRIVER HEATED SEAT SWITCH DRIVERS INFORMATION CENTER (DIC) SWITCH FOG LAMP SWITCH FRONT PASSENGER DOOR MODULE (FPDM) FRONT PASSENGER HEATED SEAT SWITCH HEAD UP DISPLAY (HUD) HEAD UP DISPLAY (HUD) SWITCH HVAC CONTROL MODULE I/P COMPARTMENT LAMP, SWITCH IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) INSTRUMENT PANEL INTEGRATION MODULE (IPM) LT BLU WIRE RADIO REAR ACCESSORY POWER OUTLET REAR COMPARTMENT LID RELEASE SWITCH REMOTE PLAYBACK DEVICE CD CHANGER SPLICE PACK THEFT DETERRENT CONTROL MODULE TRACTION CONTROL SWITCH SHIFT INDICATOR LAMP TURN SIGNAL/ HAZARD FLASHER MODULE W/AUTO A/C W/FLOOR CONSOLE FRONT COMPARTMENT WHT WIRE

Get access

BATTERY BLK WIRE CELLULAR ANTENNA COAX COIL CONTACTS DASH INTEGRATION MODULE (DIM) ELECTRONIC COMPASS MODULE F/PMP RELAY F/TNKDR RELAY F/TNKDRLOCK RELAY GARAGE DOOR OPENER IGN 1 RELAY IGN-3 RELAY INSIDE REAR VIEW MIRROR INTERIOR LAMP SWITCH LEFT BACK-UP LAMP MARKER LAMP LEFT READING/ COURTESY LAMP LEFT REAR DOOR MODULE (LRDM) LEFT TAIL/STOP LAMPS LEFT TURN SIGNAL LAMP LEFT VANITY MIRROR NCA WIRE READING/ COURTESY LAMPS REAR INTEGRATION MODULE (RIM) REAR WINDOW DEFOGGER REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) RIGHT READING/ COURTESY LAMP RIGHT VANITY MIRROR SPLICE PACK UNIVERSAL GARAGE DOOR OPENER VEHICLE COMMUNICATION UNIT (VCU) WHT WIRE

Get access

ACCESSORY INFLATOR SWITCH AUTOMATIC LEVEL CONTROL COMPRESSOR BLK WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) FUEL PUMP, SENDER ASSEMBLY LEFT FOG LAMP LEFT LICENSE LAMP PNK WIRE POWER SUNROOF MODULE REAR COMPARTMENT LID RELEASE ACTUATOR RIGHT BACK-UP LAMP RIGHT FOG LAMP RIGHT HIGH BEAM HEADLAMP RIGHT LICENSE LAMP RIGHT LOW BEAM HEADLAMP RIGHT REAR MARKER LAMP RIGHT REAR TURN SIGNAL LAMP RIGHT TAIL/STOP LAMPS SPLICE PACK VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
