Cruise control circuit for Pontiac Bonneville X (2000-2005)
Cruise control circuit
55 72 64 VEHICLE SPEED OUT INHIBIT OUTPUT VSS HIGH
BLK WIRE
CR CONT FUSE
CRUISE CONTROL MODULE (ON LEFT STRUT TOWER)
CRUISE CONTROL SWITCH
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGAGED INPUT
GRY WIRE
GRY/BLK WIRE
HEADS UP DISPLAY
HOT AT ALL TIMES
HOT IN ON, START
IGN 1 FUSE
INSTRUMENT PANEL CLUSTER
LT BLU/BLK WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
PPL
PPL VSS LOW
REAR FUSE BLOCK (UNDER REAR SEAT)
RESUME/ACCEL
SET/COAST
SPLICE PACK
STOP LP FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL BRACKET)
TCC/ CRUISE RELEASE SWITCH
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
