Pontiac Bonneville X (2000-2005) Pass-key circuit

58 59 PPL PPL 1807 1807 SERIAL DATA CLASS 2 B+ KEY DATA B+ BLK WIRE BLK/WHT WIRE CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR) DK GRN WIRE HEADLIGHT SYSTEM HORN CTRL LIGHTS CTRL HORNS SYSTEM HOT AT ALL TIMES IGN IGN SW FUSE 29 IGNITION SWITCH INSTRUMENT CLUSTER KEY DATA B+ RETURN NCA WIRE ORG/ WIRE PCM BATT FUSE 8 POWERTRAIN CONTROL MODULE (IN AIR CLEANER HOUSING) PPL PPL 1807 1807 COMPUTER DATA LINES SYSTEM PPL PPL 1807 1807 COMPUTER DATA LINES SYSTEM SERIAL DATA CLASS 2 PPL PPL 1807 1807 SERIAL DATA CLASS 2 PPL PPL 1807 1807 SERIAL DATA CLASS 2 COMPUTER DATA LINES SYSTEM REAR FUSE BLOCK REAR INTEGRATION MODULE (RIM) (BEHIND UPPER LEFT REAR SEAT CUSHION) RETURN SPLICE PACK THEFT DETERRENT EXCITER MODULE (RIGHT SIDE OF STEERING COLUMN) UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
