Pontiac Bonneville X (2000-2005) powertrain control module Wiring diagrams
This page contains all the electrical diagrams for the component. powertrain control module, in which he is found in the car Pontiac Bonneville X (2000-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram powertrain control module (1 of 2)
1 RELAY
A/C CLU FUSE
A/C CLUTCH RELAY
ACCY FUSE
ACCY RELAY
AIR FUSE
AIR PUMP RELAY
AUTOMATIC TRANS- AXLE IGNITION CONTROL MODULE
AUX PWR FUSE
BATTERY
BLK WIRE
C/LTR FUSE 20
CIGAR LIGHTER
COOL FAN 1 FUSE CIRCUIT BREAKER
COOL FAN 1 RELAY (LOW SPEED)
COOL FAN 2 FUSE
COOL FAN 2 RELAY (HIGH)
COOL FAN S/P RELAY
CR CONT FUSE
DK GRN WIRE
DRL RELAY
FOG LP RELAY
FOG/ DRL FUSE
FROM FOG/ DRL FUSE (DIAGRAM 1 OF 4)
FROM PCM BATT FUSE (DIAGRAM 1 OF 4)
FRONT AUXILIARY POWER OUTLET
FUEL INJECTOR 2 CRUISE CONTROL MODULE
FUEL INJECTOR 4
FUEL INJECTOR 5 FUEL INJECTOR 3 FUEL INJECTOR 1
FUEL INJECTOR 6
FUSIBLE LINK
GENERATOR
HDHI BML FUSE HDHI BMR FUSE
HDLO BML FUSE HDLO BMR FUSE
HDLP HI BM RELAY
HDLP LO BM RELAY
HEATED OXYGEN SENSOR (BANK 1, SENSOR 1) HEATED OXYGEN SENSOR (BANK 1, SENSOR 2)
HORN FUSE
HORN RELAY
IGN 1 FUSE
IGN 1 RELAY
INJR 1 FUSE
INJR 2 FUSE
LT GRN WIRE
MASS AIRFLOW SENSOR
ORG/ WIRE
OXY SEN FUSE
PCM BATT FUSE ABS FUSE
PCM IGN FUSE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER- TRAIN CONTROL MODULE ELECTRONIC BRAKE CONTROL MODULE
POWERTRAIN CONTROL MODULE
REAR AUXILIARY POWER OUTLET
RED WIRE
RIGHT HIGH BEAM HEADLAMP LEFT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP LEFT LOW BEAM HEADLAMP
SPEED
SPLICE PACK
START 1 RELAY
STARTER SOLENOID
TAN WIRE
THEFT DETERRENT CONTROLLER MODULE
TO BODY FUSE (DIAGRAM 2 OF 4)
TO CIGAR RELAY (DIAGRAM 2 OF 4)
TO HDLP LO BM RELAY (DIAGRAM 1 OF 4)
TO IGN 1 RELAY (DIAGRAM 1 OF 4)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 4 OF 4)
TRANS FUSE DIS FUSE
UNDERHOOD FUSE BLOCK
W/ B+ MODE
W/ BATTERY SAVER MODE
WHT WIRE
WIND- SHIELD WIPER MOTOR
WIND- SHIELD WIPER SWITCH (FRONT OF RIGHT FRONT FENDER)
WSW FUSE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> POWERTRAIN CONTROL MODULE
Wiring diagram powertrain control module (2 of 2)
A/C CLUTCH RELAY
BRN WIRE
DASH INTEGRATION MODULE
ELC RELAY
FOG LAMP RELAY
FROM ACCY RELAY (DIAGRAM 1 OF 4)
FROM IGN 1 RELAY (DIAGRAM 2 OF 4)
FROM IGN SW FUSE (DIAGRAM 3 OF 4)
FROM IGN-1 RELAY (DIAGRAM 1 OF 4)
FROM IGN-3 RELAY (DIAGRAM 3 OF 4)
IGNITION SWITCH
LOCK UNLOCK
ORG/ WIRE
PARK RELAY
PNK WIRE
POWERTRAIN CONTROL MODULE
REAR DEFOG RELAY
REAR FUSE BLOCK
RUN WIRE
THEFT DETERRENT CONTROL MODULE
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> POWERTRAIN CONTROL MODULE
