Wiper/washer circuit for Pontiac Bonneville IX (1991-1999)
Wiper/washer circuit
5 6 0 1.2 6 0 0 0
BLK WIRE
COVER ASSEMBLY
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HI MIST
HOT IN ACCY OR RUN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LATCH ARM
LEFT FRONT FENDER)
LO OFF
LO OFF PULSE
LO PULSE
MIST
MIST HI
NCA WIRE
OFF
OFF LO PULSE
PARK SWITCH
PNK WIRE
PPL
PPL WIND- SHIELD WIPER/ WASHER MODULE (LEFT REAR OF ENGINE COMPT)
RED WIRE
SOLID STATE
WASHER SWITCH
WIND- SHIELD WIPER SWITCH
WINDSHIELD WASHER PUMP
WIPER MOTOR
WIPER SWITCH
WPR/WSHR
YEL WIRE
