Electrochromic mirror circuit for Pontiac Bonneville IX (1991-1999)
Electrochromic mirror circuit
AMBIENT SENSOR (WIND- SHIELD SIDE)
AUTOMATIC DAY/ NIGHT MIRROR
AUTOMATIC DAY/NIGHT MIRROR
BLK (OR BLK/WHT) WIRE
BLK WIRE
BLK/WHT WIRE
BUICK, PONT
CHIME FUSE 10
GROUND
GRY WIRE
HEADLAMP SENSOR (MIRROR SIDE)
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
LEFT OUTSIDE MIRROR (BUICK, OLDS W/ AUTOMATIC OUTSIDE MIRROR ONLY)
LT GRN WIRE
MIRROR SWITCH
NCA WIRE
OFF MAX MIN SENSITIVITY SETTINGS
OLDS
ON INDICATOR CONTROL
OUTSIDE MIRROR REFLECTIVITY CONTROL
PARK/ NEUTRAL POSITION (PNP) SWITCH (TOP LEFT SIDE OF TRANS)
PNK WIRE
PNK/BLK WIRE
RESET TO DAYTIME HIGH REFLECTIVITY IN REVERSE
SIG/BU/LPS/BTSI/LCM FUSE 18
SOLID STATE
TURN SIGNAL FLASHER PNK WIRE
