Electronic level control for Pontiac Bonneville IX (1991-1999)
Electronic level control
BATTERY
BLK WIRE
BRN WIRE
COMPRESSOR ASSEMBLY
COMPRESSOR SIGNAL
DISTRIBUTION CENTER (BEHIND RIGHT SIDE OF I/P)
DK BLU WIRE
DK GRN WIRE
ELC COMPRESSOR ASSEMBLY
ELC FUSE
ELC HEIGHT SENSOR (UNDER RIGHT REAR OF VEHICLE, ON LOWER SUSPENSION ARM)
ELC RELAY (POSITION E)
ELC RELAY CONTROL
EXHAUST SIGNAL
EXHAUST SOLENOID
GROUND
HOT AT ALL TIMES
HOT IN RUN ABS/CCR/ ELC
I/P FUSE BLOCK
INFLATOR OUTPUT
INFLATOR SOLENOID VALVE
INFLATOR SWITCH
INFLATOR TIMER RELAY
LT BLU WIRE
NCA WIRE
OFF INPUT ON INPUT
POWER INPUT
PPL
RED WIRE
RIGHT I/P POWER
RIGHT MAXIFUSE BLOCK (RIGHT REAR ENGINE COMPT)
WHT WIRE
YEL WIRE
