Pontiac Bonneville IX (1991-1999) uart data uart data Wiring diagram

15 30 UART DATA UART DATA 15 59 UART DATA DATA CLSS 2 PPL AT RIGHT SIDE I/P, PONT.-I/P HARN., BLK WIRE BLK/WHT WIRE BUICK, OLDS W/ DUAL ZONE A/C COMPUTER COMMAND RIDE CONTROLLER (UNDER DRIVER'S SEAT) DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P, RIGHT OF STEERING COLUMN) DIAG OUT DIAG ENABLE DK GRN WIRE E&C SERIAL ELECTRONIC BRAKE (AND TRACTION) CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) GRN WIRE HEATER AND A/C CONTROL ASSEMBLY (PONT. W/ AUTO A/C) HOT AT ALL TIMES HVAC PROGRAMMER (BUICK DUAL ZONE A/C) (BEHIND RIGHT I/P) HVAC PROGRAMMER (OLDS DUAL ZONE A/C) (BEHIND RIGHT I/P) HVAC PROGRAMMER (PONT. AUTO A/C) (BEHIND RIGHT I/P) HVAC PROGRAMMER (W/ AUTO OR DUAL ZONE A/C) (RIGHT SIDE OF I/P) I/P FUSE BLOCK INSTRUMENT CLUSTER (OLDS EXCEPT DUAL ZONE) LT BLU WIRE LT GRN WIRE OR AUTO A/C W/O DUAL ZONE ORG/ WIRE PONT. AUTO A/C PONTIAC OTHERS POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) PPL PROG ENABLE DATA CLSS 2 PPL RADIO RDO, CLSTR, MISC FUSE REMOTE FUNCTION ACTUATOR MODULE (BEHIND RIGHT I/P, NEXT TO FUSE/RELAY BOX) SENSING AND DIAGNOSTIC MODULE (SDM) (BELOW RIGHT FRONT SEAT, UNDER CARPET) TAN WIRE TRANSAXLE CONTROL INDICATOR DECODER MODULE (CENTER CONSOLE) UART DATA UART DATA UART DATA W/ DUAL ZONE OR AUTO A/C
