Pontiac Bonneville IX (1991-1999) lateral accel sw out ppl wot input wiring diagram

ABS/CCR/ELC BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER COMMAND RIDE CONTROL MODULE (BELOW LEFT FRONT SEAT) DATA LINK CONNECTOR (RIGHT SIDE OF STEERING COLUMN) DIAGNOSTIC TEST IN DIAGNOSTIC TEST OUT DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER SHIFT SELECT SWITCH GROUND GROUND PPL GROUND GRY WIRE HOT IN RUN I/P FUSE BLOCK (LEFT SIDE OF I/P) IGN INPUT JUNCTION CONNECTOR LATERAL ACCEL SW IN LATERAL ACCEL SW OUT PPL WOT INPUT LATERAL ACCELERATION SWITCH LEFT FRONT STRUT SENSOR LEFT REAR STRUT SENSOR LF MOTOR DRIVE LF POSITION IN LF POSITION OUTPUT LR MOTOR DRIVE LR POSITION IN LR POSITION OUTPUT LT BLU WIRE LT GRN WIRE NCA WIRE PERF PNK WIRE POS OUT 3 PNK POS OUT 2 WIRE POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, IN AIR CLEANER ASSEMBLY) PPL RED WIRE RED/BLK WIRE RF MOTOR DRIVE RF POSITION IN RF POSITION OUTPUT RIGHT FRONT STRUT SENSOR RIGHT REAR STRUT SENSOR RR MOTOR DRIVE RR POSITION IN RR POSITION OUTPUT SWITCH 2 SWITCH 3 TOUR VEHICLE SPEED INPUT VEHICLE SPEED OUTPUT WHT/BLK WIRE WOT/BRAKE CONTROL YEL WIRE
