Pontiac Bonneville IX (1991-1999) door open in headlamp switch Wiring diagram

1450 640 1732 540 156 GND BAT CRTSY (+) BAT CRTSY (-) BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (MALL) (RIGHT SIDE OF I/P) CHIME COVER SWITCH CTSY PWR MIR DIMMER SWITCH DK BLU WIRE DOOR OPEN IN HEADLAMP SWITCH DR LKS FUSE 1 GRN WIRE HEADLAMP SWITCH INTERIOR LAMP CONTROL HOT AT ALL TIMES HOT IN ACC, RUN HOT IN RUN, BULB TEST OR START HOT W/ HEADLAMP SWITCH IN PARK OR HEAD I/P COMPARTMENT LAMP I/P COMPARTMENT LAMP SWITCH I/P FUSE BLOCK I/P FUSE BLOCK RADIO INSIDE REAR VIEW MAP LAMPS INTERIOR LAMP CONTROL INTERIOR LPS JOINT CONNECTOR LEFT DOOR FLOOD LAMP LEFT FOOTWELL COURTESY LAMP LEFT FRONT DOOR COURTESY LAMPS LEFT FRONT DOOR HANDLE SWITCH LEFT FRONT DOOR LOCK SWITCH LEFT FRONT VANITY MIRROR LEFT REAR DOOR COURTESY LAMP LEFT REAR DOOR LATCH SWITCH RIGHT FRONT DOOR LOCK SWITCH LEFT REAR RAIL COURTESY/ READING LAMP (W/ ASTRO- ROOF) LEFT REAR RAIL LAMP LT GRN WIRE LT GRN/BLK WIRE LUGGAGE COMPART- MENT LATCH SWITCH LUGGAGE COMPARTMENT LAMP NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK IGN DOOR OPEN DOOR OPEN INT LMP IN DOOR HNDL 49 126 1393 WIRE PNK WIRE REAR DOME READING LAMPS REMOTE FUNCTION ACTUATOR (RFA) MODULE (RIGHT SIDE OF I/P) RIGHT DOOR FLOOD LAMP RIGHT FOOTWELL COURTESY LAMP RIGHT FRONT DOOR COURTESY LAMPS RIGHT FRONT DOOR HANDLE SWITCH RIGHT FRONT VANITY MIRROR RIGHT I/P POWER DISTRIBUTION CENTER RIGHT REAR DOOR COURTESY LAMP RIGHT REAR DOOR LATCH SWITCH RIGHT REAR RAIL COURTESY/ READING LAMP (W/ ASTRO- ROOF) RIGHT REAR RAIL LAMP TAN WIRE WHT WIRE YEL WIRE
