Pontiac Aztek I (2001-2005) tft sens sig fuel level sens sig 12 volt ref ppl Wiring diagram

12 VOLT REF LOW REF 14 15 16 17 18 PNK WIRE A/C COMP RLY CTRL A/C REFRIGERANT PRESSURE SENSOR (BELOW AIR CLEANER) AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM (W/ TRACTION CONTROL) BLK WIRE BLK/ WHT WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE OIL LEVEL INDICATOR SWITCH (MOUNTED ON OIL PAN) EVAP CAN VENT SOL CTRL FUEL PUMP RELAY CTRL EGR SOL HI CTRL MIL CTRL FUEL INJ FUSE 11 FUEL INJECTORS FUSE 27 GENERATOR TURN ON SIG GRY WIRE HEATED OXYGEN SENSOR 1 (ON EXHAUST MANIFOLD, RIGHT SIDE OF ENG) HEATED OXYGEN SENSOR 2 (ON EXHAUST SYSTEM, BEHIND CATALYTIC CONVERTER) HOT IN RUN OR START IAC COIL A HI CTRL ENGINE SPEED SIGNAL DELIVERED TORQUE IAC COIL A LO CTRL PC SOL VAL HI CTRL PC SOL VAL LO CTRL IAC COIL B LO CTRL IAT SENS SIG INJ 4 CONTROL LOW REF LOW REF AIR PUMP RELAY CONTROL CRANK RLY CTRL LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENG COMPT, (IN AIR CLEANER ASSEMBLY) PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE SENSORS FUSE 10 STARTING/ CHARGING SYSTEM TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCC PWM SOL CTRL TCC RELEASE SW SIG TFT SENS SIG FUEL LEVEL SENS SIG 12 VOLT REF PPL TPS SENS SIG TRS SIG P TRANS FLUID PRESS SW C TRS SIG A OIL PRESSURE SW SIG UNDER- HOOD FUSE BLOCK WHT WIRE YEL WIRE YEL/BLK WIRE
