Pontiac Aztek I (2001-2005) rsa enable amp cntrl battery Wiring diagram
This page shows the only wiring diagram for the component.rsa enable amp cntrl battery, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rsa enable amp cntrl battery (1 of 1)
493 493 927 PPL PPL PPL
AMP SIGNAL
AUDIO AMPLIFIER (UNDER DASH, BETWEEN PARK BRAKE LEVER, STEERING COLUMN)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN CONSOLE)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
EXT RANGE
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR SPEAKER
LF AUDIO + 200 117 RF SPEAKER + LR SPEAKER + LF SPEAKER + LF SPEAKER -
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PPL
RD AMP FUSE 38
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SPEAKER
RSA ENABLE AMP CNTRL BATTERY
SUBWOOFER
SUBWOOFER EXT RANGE
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Premium sound radio circuit, with rear controls (2 of 2) -> RSA ENABLE AMP CNTRL BATTERY
