Pontiac Aztek I (2001-2005) (roof harn, overhead Wiring diagram
This page shows the only wiring diagram for the component.(roof harn, overhead, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (roof harn, overhead (1 of 1)
ACCY RELAY RAP RELAY
AIR TEMPERATURE ACTUATOR (LEFT)
AIR TEMPERATURE ACTUATOR- RIGHT
AUDIO AMPLIFIER
AUXILIARY DROP CONNECTOR
AUXILIARY POWER DROP CONNECTOR
AUXILIARY POWER OUTLET (REAR)
AUXILIARY POWER OUTLET- CENTER CONSOLE (LOWER)
AUXILIARY POWER OUTLET- CENTER CONSOLE (UPPER)
BACKUP LAMP- RIGHT
BLK WIRE
BLOWER MOTOR RESISTOR ASSEMBLY
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL INDICATOR SWITCH
CENTER HIGH MOUNTED STOPLAMP (CHMSL) INSIDE REAR VIEW MIRROR
CIGAR LIGHTER
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DRIVER INFORMATION CENTER (DIC) SWITCH
FLASHER
FROM LEFT ROOF RAIL READING LAMP BREAKOUT)
FUSE BLOCK-CENTER CONSOLE
HEAD UP DISPLAY (HUD)
HEAD UP DISPLAY (HUD) SWITCH
HEAD- LAMP SWITCH
HEATED SEAT SWITCH
HVAC CONTROL MODULE
I/P COMPARTMENT LAMP
IGN-3 RELAY
INSTRUMENT PANEL CLUSTER (IPC)
KEY-IN IGNITION SWITCH
LEFT REAR PARK/STOP/ TURN SIGNAL LAMP BACKUP LAMP- LEFT
LEFT VANITY MIRROR
LIFT WINDOW RELEASE SWITCH, TRACTION CONTROL SWITCH
MODE ACTUATOR
PASS-THROUGH BREAKOUT)
RADIO
REAR SEAT AUDIO CONTROL (W/RADIO CONTROL REAR SEAT, EARPHONE JACKS)
REAR SEAT ENTER- TAINMENT ASSEMBLY
RECIR- CULATION ACTUATOR
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR PARK/STOP/ TURN SIGNAL LAMP
RIGHT ROOF RAIL READING LAMP LEFT ROOF RAIL READING LAMP RIGHT VANITY MIRROR
SPLICE PACK
SUNROOF MODULE (W/ELECTRIC SLIDING GLASS SUN ROOF)
THEFT DETERRENT CONTROL MODULE
TURN SIGNAL/ HAZARD FLASHER SWITCH
VEHICLE INTERFACE UNIT (VIU)
WINDSHIELD WASHER SOLVENT LEVEL
Go to component -> Ground distribution circuit (2 of 3) -> (ROOF HARN, OVERHEAD
