Pontiac Aztek I (2001-2005) ride ctrl serial data acces- sory volt Wiring diagram
This page shows the only wiring diagram for the component.ride ctrl serial data acces- sory volt, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ride ctrl serial data acces- sory volt (1 of 1)
AIR COMPRESSOR EXHAUST SOLENOID
AIR INFLATOR SWITCH
ALC AIR INFLATOR SOL CTRL
ALC COMPRESSOR MOTOR
ALC EXHAUST SOL CTRL
ALC INFLATOR SOL CTRL
ALC RLY CTRL COIL SUPP VOLT
AUTO LEVEL CONTROL COMPRESSOR RELAY
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
ELC ACCY FUSE
ELC BATT FUSE
GROUND
HOT AT ALL TIMES
HOT IN ACC, RUN
INFLATOR SOLENOID
LT BLU WIRE
ORG/ WIRE
PWR/ MIR FUSE
RIDE CTRL SERIAL DATA ACCES- SORY VOLT
TIMER RLY COIL CTRL
WHT WIRE
YEL WIRE
Go to component -> Electronic suspension circuit -> RIDE CTRL SERIAL DATA ACCES- SORY VOLT
