Pontiac Aztek I (2001-2005) pressure control sol valve tcc pwm sol 2-3 shift sol Wiring diagram

1-2 SHIFT SOL AUTOMATIC TRANSAXLE AUTOMATIC TRANSAXLE FLUID PRESSURE MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSAXLE FLUID TEMPERATURE SENSOR AUTOMATIC TRANSAXLE INPUT SHAFT SPEED SENSOR BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BUICK PONTIAC CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACCY, RUN, OR START HOT IN RUN OR START IGN IGN 0 IGN 0 FUSE 30 IGN 1 MAIN FUSE 27 INSTRUMENT PANEL CLUSTER INTEMIM FUSE 24 LO SW SW LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE MALFUNCTION INDICATOR LAMP MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (TOP FRONT OF ENGINE) ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL PPL DATA LINK CONNECTOR (PARTIAL) (BELOW STEERING COLUMN) PRESSURE CONTROL SOL VALVE TCC PWM SOL 2-3 SHIFT SOL RED WIRE RED/BLK WIRE REV SW STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT) TAN WIRE TCC REL SW SW SW TCC/ BRAKE SWITCH THROTTLE POSITION (TP) SENSOR (ON TOP OF ENGINE, ON THROTTLE ASSEMBLY) TRANS SOL FUSE 7 TRANSAXLE INTERNAL MODE SWITCH (IMS) TRANSAXLE RANGE SWITCH UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY) PCM FUSE 5 VEHICLE SPEED SENSOR (VSS) (ON TRANSAXLE) WHT WIRE YEL WIRE YEL/BLK WIRE
