Pontiac Aztek I (2001-2005) power distributiopn system Wiring diagram
This page shows the only wiring diagram for the component.power distributiopn system, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power distributiopn system (1 of 1)
BAT 1 FUSE 48
BATTERY
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CRANK RELAY 58
CRANK REQ
CRANK RLY
IGN 1 MAIN FUSE 27
IGN 2 FUSE 35
IGN 3 FUSE 19
IGNITION SWITCH
IN KEY FUSE
LOCK
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTIOPN SYSTEM
PPL
RED WIRE
RUN WIRE
STARTER
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPT)
YEL WIRE
YEL/BLK WIRE
