Pontiac Aztek I (2001-2005) (passenger seat harn, under passenger Wiring diagram
This page shows the only wiring diagram for the component.(passenger seat harn, under passenger, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (passenger seat harn, under passenger (1 of 1)
AUTO LEVEL CONTROL (ALC) HEIGHT SENSOR
AUTO LEVEL CONTROL (ALC) SOLENOID VALVE
AUTO LEVEL CONTROL COMPRESSOR
BLK WIRE
BODY CONTROL MODULE (BCM)
BREAKOUT)
CONSOLE FUSE BLOCK BREAKOUT)
DIFFER- ENTIAL LOCK INDICATOR
DOOR LATCH ASSEMBLY- DRIVER
DOOR LOCK CYLINDER SWITCH- DRIVER
DOOR LOCK CYLINDER SWITCH- FRONT PASSENGER
DOOR LOCK SWITCH- DRIVER
DOOR LOCK SWITCH- FRONT PASSENGER
DRIVER HEATED SEAT MODULE
ENDGATE LOCK CYLINDER SWITCH LEFT ENDGATE LATCH
FROM LEFT WINDOW SWITCH BREAKOUT)
FROM RIGHT WINDOW SWITCH BREAKOUT)
FROM THE PASSTHROUGH)
FRONT PASSENGER DOOR LATCH
FRONT PASSENGER SEAT ADJUSTER SWITCH
FUEL PUMP
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
LEFT LIFT WINDOW LATCH
LEFT LIFT WINDOW LOCK ACTUACTOR
LEFT REAR DOOR LOCK
LICENSE LAMPS
MODULE BREAKOUT)
NCA WIRE
OUTSIDE REAR VIEW MIRROR CONTROL SWITCH
PASSENGER BACK HEATED SEAT ELEMENT
PASSENGER HEATED SEAT CUSHION
PASSENGER HEATED SEAT MODULE
PASSENGER OUTSIDE REARVIEW MIRROR
REAR WINDOW DEFOGGER ENDGATE LATCH
RIGHT LIFT WINDOW LATCH
RIGHT LIFT WINDOW LOCK ACTUATOR
RIGHT REAR DOOR LOCK
SEAT ADJUSTER SWITCH DRIVER
SEAT BELT SWITCH
TRAILER WIRING HARNESS
WHT WIRE
WINDOW MASTER SWITCH
WINDOW SWITCH- FRONT PASSENGER
YEL WIRE
Go to component -> Ground distribution circuit (3 of 3) -> (PASSENGER SEAT HARN, UNDER PASSENGER
