Pontiac Aztek I (2001-2005) park lmp ctl Wiring diagram
This page shows the only wiring diagram for the component.park lmp ctl, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park lmp ctl (1 of 1)
BLK WIRE
BODY CONTROL MODULE (ATTACHED TO CONSOLE) CENTER CONSOLE FUSE BLOCK
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN CONSOLE)
CENTER HIGH MOUNTED STOP LAMP
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GROUND
HAZARD SW SIG
HAZARD SWITCH
HEAD OFF
HEAD UP DISPLAY (RIGHT SIDE OF INSTRUMENT CLUSTER)
HEADLAMP SWIITCH
HOT AT ALL TIMES
HOT IN RUN, START
HZD FL FUSE 40
INSTRUMENT PANEL CLUSTER (IPC)
INTERIOR LIGHT SYSTEM
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT REAR PARK/ STOP/ TURN SIGNAL LAMP
LEFT TURN INDICATOR
LICENSE PLATE LAMP
LT BLU WIRE
LT BLU/WHT WIRE
LT RR S/T VOLT
LT TRN SIG VOLT
LT TURN SIG
LT TURN SIG VOLT
ORG/ WIRE
PARK
PARK LMP CTL
PARK LMP SIG
PARK LMP VOLT
PARK LPS FUSE 20
PARK LPS RELAY
PNK WIRE
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT REAR PARK/ STOP/ TURN SIGNAL LAMP
RIGHT TURN INDICATOR
RR AUX FUSE 14
RT RR S/T VOLT
RT TRN SIG VOLT
RT TURN SIG
RT TURN SIG VOLT
SPLICE PACK
STOP LAMP SW SIG
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TAN WIRE
TRAILER WIRING HARNESS (BLUNT CUT)
TURN SIG FUSE 19
TURN SIG SWITCH
TURN SIGNAL/ MULTIFUNCTION SWITCH
TURN SIGNAL/HAZRD FLASHER MODULE
UNDERHOOD FUSE BLOCK (RIGHT SIDE OF ENGINE COMPARTMENT)
W/ AUTO AIR LEVEL CONTROL
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> PARK LMP CTL
