Pontiac Aztek I (2001-2005) ignition battery a/c request ground Wiring diagram
This page shows the only wiring diagram for the component.ignition battery a/c request ground, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition battery a/c request ground (1 of 1)
1049 2751 58 80 SERIAL DATA LOW REFERENCE
459 380 2700 39 27 34 COMP CONTROL A/C PRESS SIG
A/C CLU FUSE
A/C CLU RELAY 52
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR DIODE
A/C REQUEST SERIAL DATA
ABOVE STARTER)
BLK WIRE
BODY CONTROL MODULE (BCM) (IN CENTER CONSOLE)
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HVAC CONTROL MODULE (CENTER OF DASH, BELOW RADIO)
IGN 1 MAIN RELAY (CLOSED IN RUN OR START)
IGN HVAC FUSE
IGNITION BATTERY A/C REQUEST GROUND
IP MISC FUSE
LT GRN/WHT WIRE
MANUAL A/C CIRCUIT
ORG/ WIRE
PPL DATALINK CONNECTOR (DLC) (BELOW STEERING COLUMN)
RED/BLK WIRE
SPLICE PACK
UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEEL- HOUSE, ABOVE BATTERY)
Go to component -> Compressor circuit, with manual a/c -> IGNITION BATTERY A/C REQUEST GROUND
