Pontiac Aztek I (2001-2005) ground aud out - drain wire Wiring diagram
This page shows the only wiring diagram for the component.ground aud out - drain wire, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground aud out - drain wire (1 of 1)
368 367 351 RT AUD SIG LT AUD SIG GROUND
AUD OUT -
BARE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
COAX ANT IN (SAT)
COAX ANT IN (TERR) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 1807 3840
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER (IF EQUIPPED)
DK GRN WIRE
DVD FUSE 21
GROUND
GROUND AUD OUT - DRAIN WIRE
HOT AT ALL TIMES
LF AUD + RT AUD +
ORG/ WIRE
PNK SERIAL DATA WIRE
PPL SERIAL DATA B+
RADIO
RADIO FUSE 37
REAR SEAT ENTERTAINMENT ASSEMBLY (IF EQUIPPED)
RT AUD SIG + LT AUD SIG + AUDIO COMMON
S- BAND FUSE 29
SPLICE PACK
UNDERHOOD FUSE BLOCK (UNDER LEFT REAR SEAT)
W/DIGITAL RADIO RECEIVER
W/O DIGITAL RADIO RECEIVER
Go to component -> Satellite radio/dvd circuit -> GROUND AUD OUT - DRAIN WIRE
