Pontiac Aztek I (2001-2005) (eng harn, top right side of Wiring diagram
This page shows the only wiring diagram for the component.(eng harn, top right side of, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (eng harn, top right side of (1 of 1)
A/C COM- PRESSOR CLUTCH DIODE
A/C COMPRESSOR CLUTCH
A/T SHIFT LEVER POSITION INDICATOR
A/T SHIFT LOCK CONTROL SOLENOID STEERING WHEEL CONTROLS- LEFT
BATTERY
BLK WIRE
BLK/WHT WIRE
COOL FAN 2 RELAY DRL RELAY
COOLING FAN (LEFT)
CRUISE CONTROL MODULE
DATA LINK CONNECTOR (DLC)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FOG LAMP (LEFT)
FOG LAMP- RIGHT
FROM STARTER BREAKOUT)
FUEL PUMP RELAY IGNITION RELAY
FUSE BLOCK- UNDERHOOD
HEAD UP DISPLAY (HUD)
HEAD UP DISPLAY (HUD) DIMMER SWITCH DRIVER INFORMATION CENTER (DIC) SWITCH
HEADLAMP SWITCH
HEADLAMP- LH
HEADLAMP- RIGHT
HEATED OXYGEN SENSOR
HORN- LEFT (LOW NOTE)
HORN- RIGHT (HIGH NOTE)
IGNITION CONTROL MODULE (ICM)
IGNITION LOCK SOLENOID
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMEMT PANEL CLUSTER (IPC)
LAMP BREAKOUT)
LAMP SWITCH BREAKOUT)
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
PARK/ TURN SIGNAL LAMP-LEFT
PARK/ TURN SIGNAL LAMP-RF
PCM BREAKOUT)
POWERTRAIN CONTROL MODULE (PCM)
RADIO
RIGHT COOLING FAN
SECONDARY AIR INJECTION (AIR) PUMP
STEERING RADIO CONTROLS- RIGHT
TRANSAXLE RANGE SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ W/
WHT WIRE
Go to component -> Ground distribution circuit (1 of 3) -> (ENG HARN, TOP RIGHT SIDE OF
