Pontiac Aztek I (2001-2005) elc batt fuse 12 Wiring diagram
This page shows the only wiring diagram for the component.elc batt fuse 12, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram elc batt fuse 12 (1 of 1)
AUTO A/C MANUAL A/C
AUTO LEVEL CONTROL INFLATION TIMER RELAY
AUTOMATIC LEVEL CONTROL AIR COMPRESSOR
BCM D FUSE 3
BLK WIRE
BODY CONTROL MODULE (BCM)
CENTER CONSOLE FUSE BLOCK
DRIVER HEATED SEAT MODULE FRONT PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER POSITIVE TEMPERATURE COEFFICIENT CIRCUIT BREAKER
ELC BATT FUSE 12
FROM BATT 2 FUSE 45 (DIAGRAM 1 OF 4)
FROM BCM L FUSE (DIAGRAM 1 OF 4)
FRONT PASSENGER POSITIVE TEMPERATURE COEFFICIENT CIRCUIT BREAKER
GARAGE DOOR OPENER
GATE REL FUSE 13
HVAC CONTROL MODULE
INSTRUMENT PANEL CLUSTER (IPC)
IP MDL FUSE 41
LEVEL CONTROL
MEMORY SEAT, MIRROR MODULE DRIVER SEAT ADJUSTER SWITCH
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PWR MIR FUSE 17
PWR STS CIRCUIT BREAKER
REAR AUXILIARY POWER OUTLET
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
RR AUX FUSE 14
SECURITY INDICATOR LAMP
SPLICE PACK
TRAILER WIRING HARNESS
W/O MEMORY SEAT W/ MEMORY SEAT
Go to component -> Power distribution circuit (4 of 4) -> ELC BATT FUSE 12
