Pontiac Aztek I (2001-2005) (driver seat harn, under driver seat, 13 cm from Wiring diagram
This page shows the only wiring diagram for the component.(driver seat harn, under driver seat, 13 cm from, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (driver seat harn, under driver seat, 13 cm from (1 of 1)
AIR BAG INDICATOR
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW STEERING COLUMN) PPL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HIGH CONTROL CLASS 2 SERIAL DATA
HIGH CONTROL LOW CONTROL LOW CONTROL
HOT IN RUN, START
IGNITION
INFLATABLE REASTRAINT I/P MODULE (RIGHT SIDE OF DASH, ABOVE GLOVE BOX)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER RIGHT FRONT SEAT)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
ING
INSTRUMENT PANEL CLUSTER (IPC)
LEFT SEAT BELT SWITCH
LOGIC
LT GRN WIRE
NCA WIRE
PPL
SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER SEAT BELT)
SERIAL DATA CLASS 2
SHORTING BAR
SIR FUSE
SPLICE PACK
TAN WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit -> (DRIVER SEAT HARN, UNDER DRIVER SEAT, 13 CM FROM
