Pontiac Aztek I (2001-2005) driver heated seat thermistor Wiring diagram
This page shows the only wiring diagram for the component.driver heated seat thermistor, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver heated seat thermistor (1 of 1)
BLK WIRE
BRN WIRE
CENTER CONSOLE FUSE BLOCK
DRIVER BACK HEATED SEAT ELEMENT
DRIVER BACK HEATED SEAT PAD
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT PAD
DRIVER HEATED SEAT MODULE
DRIVER HEATED SEAT THERMISTOR
DRIVER POSITIVE TEMPERATURE COEFFICIENT CIRCUIT BREAKER
FRONT PASSENGER
FRONT PASSENGER BACK HEATED SEAT ELEMENT
FRONT PASSENGER BACK HEATED SEAT PAD
FRONT PASSENGER CUSHION HEATED SEAT ELEMENT
FRONT PASSENGER CUSHION HEATED SEAT PAD
FRONT PASSENGER HEATED SEAT MODULE
FRONT PASSENGER HEATED SEAT THERMISTOR
FRONT PASSENGER POSITIVE TEMPERATURE COEFFICIENT CIRCUIT BREAKER
HOT AT ALL TIMES
I/P SWITCH ASSEMBLY
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PWR STS CIRCUIT BREAKER
REAR DEFOG RELAY COIL SUPPLY VOLTAGE
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> DRIVER HEATED SEAT THERMISTOR
