Pontiac Aztek I (2001-2005) a/t shift lock actuator wiring diagram
This page shows the only wiring diagram for the component.a/t shift lock actuator, which is found in the car Pontiac Aztek I (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/t shift lock actuator wiring diagram (1 of 1)
A/T SHIFT LOCK ACTUATOR
BLK WIRE
BTSI FUSE 33
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK GRN WIRE
HOT IN ACCY, RUN, OR START
HOT IN PARK OR NEUTRAL
IGNITION LOCK CYLINDER CONTROL ACTUATOR (PART OF STEERING COLUMN)
IGNITION LOCK CYLINDER CONTROL SWITCH (CLOSED IN PARK)
KEY SOL FUSE 31
LT BLU WIRE
ORG/ WIRE
PARK LOCK SOLENOID
PPL
STOPLIGHT SWITCH
TAN WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Shift interlock circuit -> A/T SHIFT LOCK ACTUATOR
