Pontiac Aztek I (2001-2005) 1049 2751 58 80 serial data low reference Wiring diagram

1049 2751 58 80 SERIAL DATA LOW REFERENCE 459 380 2700 39 27 34 COMP CONTROL A/C PRESS SIG A/C CLU FUSE A/C CLU RELAY 52 A/C COMPRESSOR CLUTCH A/C COMPRESSOR DIODE A/C REQUEST SERIAL DATA ABOVE STARTER) BLK WIRE BODY CONTROL MODULE (BCM) (IN CENTER CONSOLE) BRN WIRE CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE) DK GRN WIRE DK GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL MODULE (CENTER OF DASH, BELOW RADIO) IGN 1 MAIN RELAY (CLOSED IN RUN OR START) IGN HVAC FUSE IGNITION BATTERY A/C REQUEST GROUND IP MISC FUSE LT GRN/WHT WIRE MANUAL A/C CIRCUIT ORG/ WIRE PPL DATALINK CONNECTOR (DLC) (BELOW STEERING COLUMN) RED/BLK WIRE SPLICE PACK UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEEL- HOUSE, ABOVE BATTERY)
