Back-up lamps circuit for Plymouth Voyager III (1995-2000)
Back-up lamps circuit
AUTOMATIC DAY/ NIGHT MIRROR
AWD SOLENOID
BLK WIRE
CONTROLLER ANTI-LOCK BRAKE
HOT IN RUN JUNCTION BLOCK FUSE 12
LEFT QUARTER PANEL)
LEFT REAR LAMP ASSEMBLY BACK- UP LAMP
PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION)
RIGHT REAR LAMP ASSEMBLY BACK- UP LAMP
TRAILER TOW CONNECTOR
TRANSMISSION RANGE SENSOR (TOP OF TRANSMISSION)
VIO/BLK WIRE
W/ EAT
W/ TRAILER TOW LEFT STOP/ TURN SIGNAL RELAY
W/O EAT
WHT WIRE
