Plymouth Voyager III (1995-2000) volts indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.volts indicator lamp, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram volts indicator lamp (1 of 1)
ASD RLY OUT GEN FLD DVR ASD RLY CTRL CCD BUS (+) CCD BUS (-)
AUTO- MATIC SHUT DOWN RELAY
BAT- TERY
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (ON JUNCTION BLOCK, BEHIND LEFT SIDE OF DASH)
BRN WIRE
CCD BUS (-)
CHARGING SYSTEM IND CTRL
DK DK
DK GRN WIRE
ENGINE STARTER MOTOR
FUSE 17
FUSE 2
FUSIBLE
GENERATOR
GRN WIRE
GROUND DIST- RIBUTION SYSTEM (SPLICE
GRY WIRE
HOT IN OFF, RUN OR START
IGN CCD BUS (-)
INSTRUMENT CLUSTER
JUNCTION BLOCK
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION CENTER
POWERTRAIN CONTROL MODULE (LEFT FENDER SIDE SHIELD)
RED WIRE
VIO WIRE
VIO/BRN WIRE
VOLTS INDICATOR LAMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Charging circuit -> VOLTS INDICATOR LAMP
