Plymouth Voyager III (1995-2000) tach- meter ctrl charging system ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.tach- meter ctrl charging system ind ctrl, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tach- meter ctrl charging system ind ctrl (1 of 1)
BLK/LT BLU WIRE
BLK/RED WIRE
BLK/TAN WIRE
BRN WIRE
CCD BUS (-) CCD BUS (+)
DK BLU/YEL WIRE
DK GRN/ORG WIRE
DK GRN/RED WIRE
ENGINE COOLANT TEMPERATURE SENSOR (ON THERMOSTAT HOUSING)
EVAP LEAK DETECTION PUMP (LEFT SIDE OF CROSSMEMBER)
GRY/BLK WIRE
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
INSTRUMENT CLUSTER
INTAKE AIR TEMP- PERATURE SENSOR (ON INTAKE MANIFOLD)
LT BLU/BRN WIRE
MANIFOLD ABSOLUTE PRESSURE SENSOR (ON FRONT OF INTAKE MANIFOLD)
ORG/BLK WIRE
ORG/DK BLU WIRE
RED/WHT WIRE
TACH- METER CTRL CHARGING SYSTEM IND CTRL
TAN/BLK WIRE
TAN/WHT WIRE
TAN/YEL WIRE
THROTTLE POSITION SENSOR (ON THROTTLE BODY)
TORQUE CONVERTER CLUTCH SOLENOID (ON TRANSMISSION)
VIO/BRN WIRE
VIO/WHT WIRE
VOLTS IND TACHOMETER
W/O EATX
WHT/BLK WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.4ls (2 of 3) -> TACH- METER CTRL CHARGING SYSTEM IND CTRL
